Ultra-slim and Light Weight
Seamless integrated frame design, 30%-60% lighter than traditional one,reduce the structure load and installation cost.
Transparent & Less Wind Load
35%-85% transparent rate varies with the pixel pitches,effectively reduces wind-drag .
Lower Power Consumption
< 100W/m2( avg. power consumption)
High and Low Temperature Protection
All-weather resistant: -40 ℃~60 ℃ and various wet weather conditions
Customized Design
Suitable for different building external wall, it can manufacture according to the shape of building facade. Match with the building design perfectly.
High Brightness Optional
The brightness can reach up to 13000nit/㎡, dedicated visibility under strong direct sunlight.
IP67 Waterproof and Dustproof Design
Integrated glue process design, IP67 full protection
Easy to Maintain
Easy front / Rear service by one person.
Galaxy Series - DIP Mesh Curtain LED Screen SMD/DIP DIP Pixel Pitch(H*V)(mm) P15.625 P16.67 P20 P25 P15.625-31.25 P31.25 Pixel Density(dots/㎡) 4096 3600 2500 1600 2048 1024 Brightness(cd/㎡) 6000-10000 6000-9000 6000-8000 6000-8000 6000-10000 5000-6000 LED Lamp DIP346 Cabinet Size 500*1000mm(500*500mm /1000*1000mm optional) Cabinet Resolution 32*64 30*60 25*50 20*40 16*32 16*16 Panel Maximum Power(W) 200W 175W 200W 150W 175W 100W Panel Average Power(W) 70W 60W 60W 60W 80W 60W Max.Power Consumption(W/㎡) 400w 400W 400W 300w 400W 300W Power distribution 400w 400W 400W 400W 400W 400W Transparency Rate 38% 32% 50% 60% 68% 68% Viewing Distance(m) ≧16m ≧18m ≧20m ≧25m ≧25m ≧32m Weight(kg/㎡) 18.4KG 18KG 13KG 13KG 12KG 12KG Viewing Angle(left/right) 120°±5° Viewing Angle(up/down) 60°±5° Driving Method Static State LED Driving Method MBI5120 Materials Aluminium Profile & PC mask & Die-casting Lock Pixel Composition 1R1G1B Operating Input Voltage(V) 5V Control System NOVA Gray Scale ≧14bits Brightness Adjustment 256 Brightness Levels Refresh Rate 3840(All products can reach) Refresh Frame Frenquncy ≧60HZ Maintenance Way Front/Rear(Depends on the installation environment) Ingress Protection IP66 Continuous Use Time >72h Life Span 100,000h MTBF >10,000h Blind Spot Rate <0.01% Operating Temperature -20℃～+50℃(Below -20 degrees could be customized) Operating Humidity Outdoor 10% - 90%
Curtain Mesh
Galaxy Series
DIP Mesh Curtain LED Screen
Dimension: 500x1000mm/ 500x500mm/ 1000x1000mm
Pixel Pitch: P15.625/ P16.67/ P20/ P25/ P15.625-31.25/ P31.25/ P25-50
High Brightness up to 15000nits/㎡
1/3 Energy-saving compare with traditional outdoor screen
Applications: Media Facade, Building Roof, Outdoor Advertising
